What is E for 2014 T6 aluminum?
Young’s modulus: 73 GPa, or 11 Msi. Electrical conductivity: 34 to 50% IACS. Ultimate tensile strength: 190 to 480 MPa, or 28 to 70 ksi.
What is T6 metal?
6061 T6 is one of the most commonly requested versions of 6061 aluminum. The T6 refers to the temper or degree of hardness, which is achieved by precipitation hardening. This grade has a good strength-to-weight ratio and is also heat-treatable.
What is a typical application of an Aluminium alloy such as 2014?
Machinability of aluminium alloy 2014A is very good. Typical applications of aluminium alloy 2014A are high strength componenets especially for use in the aerospace and defence industries.
What is the coefficient of thermal expansion for 2014 t6 aluminum?
Aluminum 2014-T6; 2014-T651
| Physical Properties | Metric | English |
|---|---|---|
| Thermal Properties | ||
| CTE, linear 68°F | 23 µm/m-°C | 12.8 µin/in-°F |
| CTE, linear 250°C | 24.4 µm/m-°C | 13.6 µin/in-°F |
| Specific Heat Capacity | 0.88 J/g-°C | 0.21 BTU/lb-°F |
Can you form 2024 aluminum?
2024 is can be formed in the annealed condition. 2024 can be forged or hot worked, however subsequent heat treatment is necessary in order to retain reasonable corrosion resistance.
What is T6 hardening?
4 Heat-Treatable Alloys. Here, the T6 temper means that the alloy is solution treated at high temperatures and then artificially aged at a certain temperature (for example, 420–480K) to yield the precipitation hardening of alloys.
What is the modulus of elasticity of 2014 t6 aluminum in KSI?
73.1 GPa 10600 ksi
| Physical Properties | Metric | English |
|---|---|---|
| Modulus of Elasticity | 73.1 GPa | 10600 ksi |
| Tensile Modulus | 72.4 GPa | 10500 ksi |
| Compressive Strength | 470 MPa | 68200 psi |
| Compressive Modulus | 73.8 GPa | 10700 ksi |
